Byssus Threads Resist Forces

Biological Strategy

Common mussel

AskNature Team

Manage Tension

When a living system is under tension, it means there is a force pulling on it, like a person pulling on a rope tied to a horse. When applied to a living system, unless the system is completely rigid, the result is that it gets stretched. If stretching exceeds the strength of the living system’s material, it can damage it. Living systems manage tension using materials that are flexible and stretchable enough to survive most tension that occurs in their environment. The ocean’s intertidal zone offers a good example. The waves and incoming and outgoing tides put tension on soft-bodied organisms. Mussels resist tension with flexible threads that hold them onto rocks; in contrast, large algae have stretchy fronds.

Search this Function

Manage Turbulence

A turbulent force occurs when air or water creates a chaotic or irregular motion. The source can be such things as wind, waves, and eddies caused by obstructions to air or water flow (such as that created by a rock in a stream). Because the force is irregular, it acts in unpredictable ways on multiple parts of a living system at any given time, decreasing the living system’s efficiency. Strategies used to manage turbulence include dampening the amount of turbulence, having flexibility to handle sudden changes, and making quick adjustments. An example is the mucus on aquatic organisms, such as barracuda sharks, that can reduce turbulent friction of seawater by 66%. In doing so, it decreases drag and increases the sharks’ swimming efficiency.

Search this Function

Bivalves

Class Bivalvia (“two-valved”): Clams, mussels, oysters

The bivalve name says it all: these animals are characterized by a two-sided shell that is connected at the hinge with a muscle. The 15,000 species in 90 families have flattened bodies, no head, and generally live a sedentary lifestyle. Instead of having a circular band of teeth like other molluscs, many are filter feeders. They use cilia, or hair-like extensions, to move water into their bodies and pluck out plankton to eat. Consequently, there are no terrestrial bivalves, and only 15% live in freshwater ecosystems. The rest live in marine environments.

Search this Living System

The byssus threads of mollusks are strong anchors that can resist hydrodynamic forces because of mechanically distinct regions within each thread.

“One particular use of a collagenous rope gives a sense of the range of performance nature can get from this material–and of some of the peculiarities of applying data from standard analyses. As familiar to anyone who has poked around rocky, wave-swept shores, mussels don’t dislodge easily. Each is attached to rocks by twenty to sixty stringy byssus threads of sufficient tenacity to resist extreme hydrodynamic forces. (Denny [1988] provides an especially good view of the origin of these forces.) At first glance, a collagenous material looks inappropriate for the mission. After all, low extensibility means that unless particularly well matched and faced with forces of invariant strength and direction, only some subset of threads will bear the load. Imagine hanging from a group of inextensible ropes each of slightly different length–having more than one will gain you nothing, since they’ll break one by one instead of sharing the load.

A byssus thread contains two mechanically distinct regions, called, for their distance from the shell, proximal and distal. The material of both regions proves to be unusually extensible for collagens, which sounds right and proper. But then, according to Bell and Gosline (1996) things get more complex. The proximal region can be strained to a greater fraction of unloaded length, but it never achieves the breaking strength of the distal region, as you can see from figure 16.14a. So it looks as if their proximal regions take care of distributing the load among the threads. Not so. The distal region of threads happens to be two to four times longer and only half as wide. So a given force will stretch it quite far. Replotting the data as force against extension for a whole thread as a structure, as in figure 16.14b, shows a nice match. Even better, it shows how the distal thread yields (the horizontal portion of its curve) just short of the breaking force–an extension that will permit threads to reorient closer to the direction of the applied force and to share increasing loads among an increasing number of threads.” (Vogel 2003:347)

Last Updated October 26, 2016

References

Book

Comparative Biomechanics: Life's Physical World, Second Edition

17/06/2013 | Steven Vogel

embedly preview

Reference

Journal article

Mechanical design of mussel byssus: material yield enhances attachment strength

E Bell, J Gosline
